For the connection of Eastron energy meters to the Eniris Gateway:

• Connection scheme: Aansluitschema SGW-WIRING-001-REV1.pdf
• Manual: SDM630MCTE-MID_User_Manual.pdf

The Eniris gateway is already pre-configured, but after connection the communication settings of the meter still need to be set.

The procedure to change the settings is described in the SDM630MCTE-MID_User_Manual attached, under section 4 "Set Up".

The necessary settings:
- Password is 1000 by default
- SEt bAUd: must be set to 9600
- SEt PArI: set to none.
- SEt StoP: must be set to 1.
- SEt Addr: must have a unique number for each energy meter. It is with this number that we identify the energy meters. Please provide us with a list of the meter name & corresponding address.

The other settings are not important for communication (possibly they are for the correct measurement of the energy, but that depends on the correct situation and model of the device).

Once the Eniris gateways are connected to the energy meter, they still have to be supplied with power using the supplied adapter and connected to the internet via Ethernet. They will contact our server themselves, so you don't need to do anything after that.
